Device Installation 20

Figure 4-2

4.4.2 Installation with 86 Box

Install the device with 86 box, which is suitable for all types of devices. Take “VTH1560B/BW ”

for example.

Embed 86 box into a wall at a proper height.

Fix installation bracket onto 86 box with screws.

Put the device into installation bracket from top down.

Figure 4-3

4.4.3 Desktop Installation with Bracket

Install the device with bracket on the desktop, which only applies to handset VTH. Take

“VTH5221E-H” for example.

Dahua Digital VTH Series User Manual
