Dahua VTH Series User Manual

13
Press to go to the monitoring image that you want.
Press , and then Successful will appear on the screen.
 When a VTO is calling or in a call with a VTO, press , and then Successful will appear on the
screen.
If the calling lasts more than 1 second, a snapshot will be automatically taken.
Viewing Snapshots
Press to bring up the menu.
Press , select Snapshots, and then press .
List of snapshots
Press to select the one that you need, and then press .
To delete a snapshot, press , Detele? will appear on the screen, and then press to
confirm.

Dahua VTH Series Specifications

General

Touch Screen	Yes
Display Type	TFT LCD
Video Compression	H.264
Display Size	7 inch
Resolution	1024 x 600
Network	Ethernet
Operation Method	Touch buttons
Audio	G.711
Network Interface	RJ45
Operating Temperature	-10°C to +55°C
