Dahua VTH2421FB-P User Manual

17
SIP server Figure 2-16
1) Set parameters of SIP server by reference to Table 2-4.
Table 2-4 SIP server description
Parameter
Description
Server IP
When the platform works as SIP server, server IP is IP address

of the platform.
When VTO works as SIP server, server IP is IP address of the

VTO.
Network Port
When the platform works as SIP server, network port is 5080.

When VTO works as SIP server, network port is 5060.

User Name
Use default value.
Register Pwd
Domain
Registration domain of SIP server, which can be null.
When VTO works as SIP server, registration domain of SIP server
shall be VDP.
User Name
User name and password to login SIP server.
Login Pwd
2) Set “Enable Status” to be .
Enable SIP server function.
3) Press [OK] to save settings.
Press [VTO Config]. Step 7
The system displays “VTO Config” interface, as shown in Figure 2-17.

Dahua VTH2421FB-P Specifications

General

Brand	Dahua
Model	VTH2421FB-P
Category	Intercom System
Language	English
