Dahua VTO7541G

Installation 7
Apply silica gel to gaps Figure 4-3
4.2.2 Installing in the Wall
Installing in the wall Figure 4-4
Table 4-2 Item list
No.
Item
No.
Item
No.
Item
1
VTO
2
Locking screw
3
Cable entry
4
Mounting box
5
Wall
–
–
Cut an opening with the size of the mounting box on the wall, and then put the Step 1
mounting box in.
Apply sealant to gaps between the mounting box and wall. Step 2
