Dahua XVR5104C-S2 - HCVR54 XXL-V2 Series

85
Model
Parameters
HCVR5204L-V2
HCVR5208L-V2
HCVR5216L-V2
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,RCA port, audio via coaxial cable
Audio Output
1-ch,RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
4-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V
Power
Consumption
≤30W（exclude HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case,440mm（W）×410mm（D）×70mm（H）
Weight
3.0kg～3.5kg（exclude HDD）
Installation
Mode
Desk installation
1.3.48 HCVR54XXL-V2 Series
Model
Parameters
HCVR5404L-V2
HCVR5408L-V2
HCVR5416L-V2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
