Dahua XVR5104C-S2 - XVR5204 AN-4 M Series

149
1.3.80 XVR5204AN-4M Series
Coaxial Audio
Input
4-channel BNC port
Audio Output
1-channel RCA port
Bidirectional
Talk Input
Reuse audio input and output port of the first channel.
Record
Record Mode
Alarm record, motion detection record, regular record, manual
record, schedule record.
Playback Mode
Instant playback, normal playback, event playback, mark playback,
intelligent playback.
Record
Playback
Max 4-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port
Space/HDD
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
1 RS485 port
USB
2 USB2.0 ports
(Two USB2.0 ports
at the rear panel. )
2 USB2.0 ports (One USB2.0 port at the
front panel and one USB2.0 port at the rear
panel. )
Other
Power
DC12V
Power
Consumption
（No HDD）
≤8W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
SMART 1U case,
270mm*205mm*41
mm（W*D*H）
Compact 1U case,
260mm*220mm*44
mm（W*D*H）
Mini 1U case,
325mm*245mm*45
mm（W*D*H）
Weight
（No HDD）
≤0.55KG
≤0.90KG
≤1.10KG
Installation
Mode
Desk installation
Model
Parameters
XVR5204AN-4M
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
