Here you can view system log. See Figure 5- 150.
Figure 5- 150
Please refer to the following sheet for log parameter information.
Log types include: system operation, configuration operation, data
operation, event operation, record operation, user management, log
clear.
Set the start time of the requested log.
Set the end time of the requested log.
You can select log type from the drop down list and then click search
button to view the list.
You can click the stop button to terminate current search operation.
You can select one item to view the detailed information.
You can click this button to delete all displayed log files. Please
note system does not support clear by type.
You can click this button to backup log files to current PC.
It is to display current online user, user group, IP address and login time.
The online user interface is shown as in Figure 5- 151.
