Dahua XVR5104C-S2 User Manual

510
Figure 5- 29
◇ Select a channel from the dropdown list and change the parameters.
◇ Click Copy, device pops up the following dialogue box. It is to copy the user name
and password to the selected channel(s). See Figure 4- 30.
Figure 5- 30
 Click to disocnnected the camera and remove it from the added list.

Select one or several device(s) in the added list, click Delete button to delete. Check
the box before the channel number to select all channels at the same time.
5.10.1.1.5 IP Export
System can export the Added device list to your local USB device.
Step 1 Insert the USB device and then click the Export button.
Enter the following interface.
Step 2 Select the directory and then click the OK button.
System pops up a dialogue box to remind you successfully exported.
Step 3 Please click OK button to exit.

Dahua XVR5104C-S2 Specifications

General

Brand	Dahua
Model	XVR5104C-S2
Category	DVR
Language	English
