Step 3 Double click a name to connect to it.
Click Refresh button, you can view latest connection status.
It is to connect to the 3G/4G network to receive alarm information, view device state,
audio/video and etc.
Step 1 From main window->Setup->Network->3G/4G.
Enter 3G/4G interface is shown as in Figure 5- 55.
Note
After you connected the 3G/4G module, you can view the module information and
wireless signal. If there is no information, click Search button to search.
Figure 5- 55
Step 2 Check the Boot up box to enable this function and then set parameters.
Here you can select 3G/4G network type to distinguish the
3G/4G module from different ISP. The types include
WCDMA,CDMA1x and etc.
Here is the important parameter of PPP.
It includes PAP,CHAP,NO_AUTH.
It is to set time to end 3G/4G connection after you close extra
stream monitor. For example, if you input 60 here, system ends
3G/4G connection after you close extra stream monitor 60
seconds.

If the pulse interval is 0, then system does not end 3G/4G connection
after you close the extra stream monitor.
