3
22
Completed!
Insert shoulder belt into shoulder pad for toddlers.
Put shoulder belt into shoulder belt hanger.
Shoulder belt with the shoulder pad should
be inserted into shoulder belt hole
at the back of safety seat.
Caution
Shoulder belt will get through smoothly
if you push it gently with your thumb.
Inner side
Outer side
Advice
Shoulder belt should not be twisted and hanged on the shoulder belt hanger.
Warning
Seat the baby into safety seat, pull out lower adjustment belt to make baby
to seat firmly (refer to Tight attachment of shoulder pad at Baby Mode on p.14).
If the belt cannot perform its function properly, it might risk a life or serious injury.
Warning
Belt cover should be attached for use.
If the belt cannot perform its function properly, it might risk a life or serious injury.
To Next Page
