How to detach headrest
How to take off seat cover
When you put the seat cover on, follow below instruction in opposite order.
☆
32
Maintenance and management
2
Pull out the headrest to the highest position.
Take off headrest.
From the backside of headrest to side,
take off the seat cover.
When you attach headrest again, as you pull headrest lever,
set each side rail in the right position and then push it.
As you pull out the lever of headrest,
push right and left side levers located
on the backside of safety seat
at the same time in order to separate headrest.
1
21
3
Do not detach front pad and the main body. This might cause breakdowns.
Warning
Side levers located
inside the seat
Side levers located
inside the seat
Pull!
