Daikin 4MXM-M User Manual

ESIE16-02B | Part 5. Appendix 5.4. Piping diagram
RA R32 Split & multi split M-Series
4/04/17 | Version 1.1 Page 107
5.4.2.6. RXJ50M
Figure 5-22: Piping diagram - outdoor unit RXJ50M
5.4.2.7. RXM20-35M
Figure 5-23: Piping diagram - outdoor unit RXJ20-35M
7.9CuT
7.9CuT
12.7CuT
12.7CuT
M
(6.4CuT)
(12.7CuT)
9.5CuT
9.5CuT
12.7CuT
12.7CuT
7.9CuT
7.9CuT
EV
Propeller fan
Heat exchanger
Outdoor air temperature thermistor
Muer with lter
Muer
Muer
4-way valve
ON: heating
Muer
Discharge pipe thermistor
Compressor
Accumulator
Liquid stop valve
Field piping
Field piping
Electronic expansion valve
Cooling
Heating
Refrigerant ow
Heat exchanger thermistor
7.9CuT
7.9CuT
7.9CuT
7.9CuT
7.9CuT
7.9CuT
6.4CuT
6.4CuT
6.4CuT
7.9CuT
7.9CuT
4.0CuT
4.0CuT
4.0CuT
4.0CuT
6.4CuT
6.4CuT
1
2
3
4
1-4
Capillary tube
Muer
9.5CuT
9.5CuT
12.7CuT
Receiver gas
Filter
Gas stop valve with service port
7.0CuT
7.0CuT
9.5CuT
9.5CuT
M
4.8CuT
4.8CuT
6.4CuT
6.4CuT
Ø.4.0xID.2.0CuT
6.4CuT
(6.4CuT)
(9.5CuT)
9.5CuT
9.5CuT
9.5CuT
9.5CuT
7.9CuT
Heat exchanger thermistor
Outdoor air temperature thermistor
Accumulator
Compressor
Muer
Muer with lter
Muer with lter
4-way valve
Motor-operated valve
Liquid stop valve
Gas stop valve
Field piping
Field piping
Heat exchanger
Discharge pipe thermistor
Propeller fan
Heating
Cooling
Refrigerant ow
ON: heating
Muer with lter
Muer
Muer
7.9CuT
