Daikin 4MXM-M

ESIE16-02B | Part 3. Repair 3.3. Unit specific repair procedures
Page 80 4/04/17 | Version 1.1
RA R32 Split & multi split M-Series
Figure 3-11: Removing the DC fan motor assembly
Installation
1. Proceed in reverse order.
1. Insulation 5. Harness retainer
2. Fan motor assembly harness 6. Screw
3. Connector 7. Fan motor assembly
4. Slot
1
3
2
6
6
7
8
7
54
