ESIE16-02B | Part 3. Repair 3.3. Unit specific repair procedures
4/04/17 | Version 1.1 Page 69
RA R32 Split & multi split M-Series
Figure 3-4: Removing the top plate
3.3.2.1.4 Removing the front plate
PRELIMINARY ACTIONS
1. Switch off the Daikin unit via the user interface.
2. Switch off the Daikin unit with the field supplied circuit breaker.
PROCEDURE
Removal
1. Remove the top plate.
2. Loosen and remove the 8 screws (1) that fix the front plate.
1. Screw
1 1
