Daikin 90 Plus AFUE - Right Side Down Drain Trap Steps

11
©2014DaikinNorthAmerica,LLC
HorizontalRightSideDown
 Removethetwo
plugsfromtheright
sideofthecabinet
andinstallthemin
theblowerdeck.
 Locatehose#5and
cutatline“C”.
 Installthecutend
ofhose#5from
outsideofthe
cabinetthroughthe
cabinetdrainhole
nearestthetopof
thefurnace.
Cut“C”
Remove
Plugs
©2014DaikinNorthAmerica,LLC
HorizontalRightSideDown
 Securehose#5to
thebarbedfittingin
theelbowwitha
redclamp.
 Installthe“non‐
grommet”endof
hose#11fromthe
outsideofthe
cabinetthroughthe
bottomdrainhole.
 Installoncollector
bo xandsecurewith
asilverclamp.
Securew/
clamp
Secure
hose#5
Install
hose#11
