Daikin 90 Plus AFUE - Volt Dehumidistat Wiring

34
©2014DaikinNorthAmerica,LLC
24VoltThermostatWiring
Two‐StageHeat,Single‐StageCool
Two‐StageHeat,Two‐StageCool
C G R
Y C G R
Y C
Y2O Y1
NEU
HOT
DE
HUM
Y
W1 W2
W1 W2
Remote
CondensingUnit
Single‐StageCooling
Dehumidistat
Optional
FurnaceIntegratedControlModule
C G R
Y C G R
Y C
O
NEU
HOT
DE
HUM
W1 W2
W1 W2
Remote
CondensingUnit
Single‐StageCooling
Dehumidistat
Optional
FurnaceIntegratedControlModule
Y2 Y1
©2014DaikinNorthAmerica,LLC
24VoltDehumidistatWiring
 Theoptionalusageofa
dehumidistat allowsthe
furnace’scirculatorblowerto
operateataslightlylowerspeed
(85%ofdesiredspeed)duringa
combinedthermostatcallfor
coolinganddehumidistat callfor
dehumidification.
 Adehumidistat appliedtothis
furnacemustoperateon24VAC.
