Daikin 90 Plus AFUE - Pressure Tube Relocation for Horizontal

13
©2014DaikinNorthAmerica,LLC
FrontCoverPressureTube(Relocating)
Relocatepressuretube
tolowercollectorbox
portwhen:
 Upflow modelis
installedhorizontal
leftsidedown.
 Downflow modelis
installedhorizontal
rightsidedown.
Pressure
Tube
©2014DaikinNorthAmerica,LLC
FrontCoverPressureSwitchTube
Step1
 Removefactory
installed6”square
tubingthatconnects
thefrontcover
pressureswitch,and
thetopcollectorbox
coverport.
Remove
tube
