Daikin 90 Plus AFUE - Gas Valve and Connections; Gas Valve Operation and Sizing

25
©2014DaikinNorthAmerica,LLC
 Suspension,Leveling,Filters,ReturnOptions
 CondensateDrainTrap,DrainPan,andLines
 HorizontalRightSideDown
 HorizontalLeftSideDown
 Venting
 GasValveandConnections
 ElectricalConnections
 24VoltThermostatWiring
 ComfortNet
 FurnaceStartUp
 TemperatureRiseandBlowerSpeedAdjust
 DuctStatic
Agenda
©2014DaikinNorthAmerica,LLC
 24voltgasvalvecontrolledby
theintegratedcontrolmodule.
 ManualON/OFFcontrollocated
onthevalveitself.
 Thegaspipingsupplyingthe
furnacemustbeproperlysized
basedonthegasflowrequired,
specificgravityofthegas,and
lengthoftherun.
GasValve
