Daikin 90 Plus AFUE - Furnace Installation Configurations; Furnace Suspension Methods

2
©2014DaikinNorthAmerica,LLC
Thenew90PlusAFUEFurnacecanbeinstalledinanupflow,downflow,
orhorizontalleftorrightapplications.
Daikin90PlusAFUEFurnaceInstallation
Horizontal
Right
Upflow
Downflow Horizontal
Right
Horizontal
Left
Horizontal
Left
©2014DaikinNorthAmerica,LLC
 Suspensionfrom
raftersorjoists
 Use3/8threaded
rod
 2”x2”x1/8”angle
iron
 Crawlspace
installation
 Suspendedfrom
floorjoists
 Supportedby
concretepad
 Neverinstallon
groundunderhome,
asitcouldbeexposed
towater
FurnaceSuspension
