Daikin 90 Plus AFUE - Furnace Leveling Procedure

3
©2014DaikinNorthAmerica,LLC
FurnaceLeveling
 Levelingensures
propercondensate
drainagefromthe
heatexchangerand
inducerdraftblower.
 Levellengthwise
fromend‐to‐endfor
properfluepipe
drainage.
Levelend‐to‐end
©2014DaikinNorthAmerica,LLC
FurnaceLeveling
Installthefurnace
withaslighttiltfrom
backtofrontwiththe
accessdoorsdownhill
fromthebackpanel.
 Tiltapproximately1/2
to3/4inches.
 Allowsthecondensate
fromthesecondary
heatexchangertoflow
forwardtothe
recuperator coilfront
cover,andintodrain
trap.
