Daikin 90 Plus AFUE - Vent Termination Clearances; Vent Termination Guidelines

22
©2014DaikinNorthAmerica,LLC
DirectandNon‐Direct
 Ifa90or45degreeelbowis
usedfortermination…it
mustbepointeddownward.
 Mustterminateatleast3’
above anyforcedairinlet
locatedwithin10’.
Non‐DirectVent
Termination:
 Atleast4’belowawindow
 4’horizontally fromadoor
orwindoworgravityairinlet
 1’aboveanydoor,
window,orgravityair
inletintoanybuilding.
VentTerminationClearances
VentTerminations
3’Min
Forced
AirInlet
4’
Min
12”
Min
No
Terminations
Above
Walkway
Non‐Direct
Non‐Direct
&Direct
Direct
Non‐Direct
©2014DaikinNorthAmerica,LLC
VentTerminations
DirectVentTerminations
 Mustterminateatleast
12”fromanyopening
throughwhichfluegases
mayenterabuilding.
(door,window,orgravity
fedinlet)
 Aventpiperunvertically
througharoofmust
terminateatleast12”
above theroofline,and
beatleast12”fromany
verticalwall.
12”MintoRooforHighest
AnticipatedSnowLevel
12”MinHeightDifference
BetweenIntakeandVent
Tee(Optional)
Combustion
AirIntake
(Optional)
