StandardHorizontalTerminations(DualPipe)
VentTerminations
 Also,maynot
terminateoverapublic
walkway ,oroverany
areawhere
condensateorvapor
couldcauseanuisance
orhazard.
 Thecombustionair
intaketerminationofa
directventapplication
shouldnotterminate
inanareawhichis
frequentlydustyor
dirt.
12”MintoGradeorHighest
AnticipatedSnowLevel
VentFluePipe
(TeeOptional)
Combustion
AirIntake
(Optional)
10”– 24”
©2014DaikinNorthAmerica,LLC
SideWallVentKit
ConcentricVentTerminations(sidewall)
 Usedwith2”or3”
directventsystems.
 Maybeinstalledwith
theintakeandexhaust
pipeslocatedside‐by‐
side orwithonepipe
abovetheother.
 Notintendedforuse
withsinglepipe/non‐
directvent
installations.
