Daikin 90 Plus AFUE - Dual Fuel System Integration

35
©2014DaikinNorthAmerica,LLC
 Turnoffpowertothefurnace.
 Set thedehumidification
“ENABLE”dipswitchfrom
OFFtoON.
 Securedehumidistat neutralwire
totheterminalmarked“DEHUM”
ontheintegratedcontrolmodule.
 Securethedehumidistat hotwire
totheterminalmarked“R”on
thefurnaceintegratedcontrol
module.
24VoltDehumidistatInstallation
OFF ON
1
2
DEHUM
TRIMENABLE
S5
©2014DaikinNorthAmerica,LLC
DualFuelApplications
 Thisfurnacecanbeusedin
conjunctionwithaheat
pumpinadualfuel
application.
 A“dualfuel”application
referstoacombinedgas
furnaceandheatpump
installation.
 Strictlyfollowthewiring
guidelinesinthedualfuelkit
installationinstructions.
