Daikin 90 Plus AFUE - Checking Electrical Polarity

30
©2014DaikinNorthAmerica,LLC
115VoltLineConnections
 Connecthot,neutral,andground
wiresasshowninthewiring
diagramlocatedontheunit’s
blowerdoor.
 Fordirectventapplications,the
cabinetopeningtothejunction
bo xmustbesealedairtight.
 Linepolaritymustbeobserved
whenmakingfieldconnections.
 Linevoltageconnections canbe
madethr
ougheithertherigh
tor
leftsidepanel.
©2014DaikinNorthAmerica,LLC
CheckingForLinePolarity
HotLeg(L1)
Common/NeutralLeg
L1toground
reading119VAC.
Neutralto
groundreading
0.3VAC
