SideReturnAirOpening
 Onupflow units,“guidedimples”
locatethesidereturncutout
locations.
 Useastraightedgetoscribelines
thatwillconnectthedimples
beforecuttingyouropening.
 NOTE: Anundersizedopeningwill
causedreducedairflow.
©2014DaikinNorthAmerica,LLC
 Suspension,Leveling,Filters,ReturnOptions
 CondensateDrainTrap,DrainPan,andLines
 HorizontalRightSideDown
 HorizontalLeftSideDown
 Venting
 GasValveandConnections
 ElectricalConnections
 24VoltThermostatWiring
 ComfortNet
 FurnaceStartUp
 TemperatureRiseandBlowerSpeedAdjust
 DuctStatic
Agenda
