DrainPan,Trap,andLines
 Thedraintrapmustbeprimed
priortofurnacestartup.
 Fillbothsidesofthedraintrap
withwater.
 Importanceofdraintrappriming:
 Ensuresproperfurnacedrainage
uponstartup
 Prohibitsthepossibilitiesofflue
gasesescapingthroughthedrain
system.
©2014DaikinNorthAmerica,LLC
DrainTrapInstalledinVerticalUpflow Furnace
DrainExitingLeftSide
DrainExitingRightSide
