Return Setting
Return Setting
Low
Position 0
Air Volume/direction
Air Volume Direction
Return Setting
Return Setting
Low
Swing
Air Volume/direction
Air Volume Direction
Airow direction
setting (up/down)
Return Setting
Return Setting
Low
Swing
Air Volume/direction
Air Volume Direction
Airow direction
setting (left/right)
• With airow direction setting selected, select the
desired airow direction from
No Ind Set
,
Position 0
,
Position 1
,
Position 2
,
Position 3
,
Position 4
,
Swing
, and
Auto
using the
buttons.
Note
• Airow direction appears on the screen as below.
1
2
3
4
0
Up/down direction
0
1
2
3
4
Left/right direction
0 : Position 0
1 : Position 1
2 : Position 2
3 : Position 3
4 : Position 4
• Selecting
Swing
will cause the airow direction
blades to swing back and forth.
For the swing setting only, all positions will be
displayed.
• When you select one of positions 0 to 4, the
airow direction blades stay in a xed position.
• Pressing Menu/Enter button conrms the settings
and takes you back to the basic screen.
Movement of airow direction blades
Under the operation conditions shown below, airow direction is controlled automatically. Actual
operation may thus be different than what is displayed on the remote controller.
Operation
condition
• Room temperature is higher than the remote controller's set temperature
(in heating mode).
• When defrosting (in heating mode).
(The airow is blowing horizontally so that people in the room are not in
direct line of the cold air.)
• Under continuous operation with the airow blowing horizontally.
Heating mode includes automatic operation.
Basic Operation Method (Use of Direct Buttons)
