EDUS721438 Operation Manual
BRC1E73 9
3P243520-7N
English 5
Operation mode selector button1.
Press this button to select the operation Ɣ
mode of your preference. (See page 10.)
Available modes vary with the indoor unit *
model.
Fan speed control button2.
Press this button to select the fan speed of Ɣ
your preference. (See page 11.)
Available fan speeds vary with the indoor *
unit model.
Menu/OK button3.
Used to enter the main menu. Ɣ
(See page 20 for the menu items.)
Used to enter the selected item. Ɣ
Up button 4.
Used to raise the setpoint. Ɣ
The item above the current selection will be Ɣ
highlighted.
(The highlighted items will be scrolled
continuously when the button is
continuously pressed.)
Used to change the selected item. Ɣ
Down button 5.
Used to lower the setpoint. Ɣ
The item below the current selection will be Ɣ
highlighted.
(The highlighted items will be scrolled
continuously when the button is
continuously pressed.)
Used to change the selected item. Ɣ
Right button 6.
Used to highlight the next items on the Ɣ
right-hand side.
Each screen is scrolled in the right-hand Ɣ
direction.
Left button 7.
Used to highlight the next items on the Ɣ
left-hand side.
Each screen is scrolled in the left-hand Ɣ
direction.
On/Off button8.
Press this button and system will start. Ɣ
Press this button again to stop the system. Ɣ
Operation lamp9.
This lamp illuminates solid green during Ɣ
normal operation.
This lamp fl ashes if an error occurs. Ɣ
Cancel button10.
Used to return to the previous screen. Ɣ
LCD (with backlight)11.
The backlight will be illuminated for Ɣ
approximately 30 seconds by pressing any
button.
If two remote controllers are used to control Ɣ
a single indoor unit, only the controller
accessed fi rst will have backlight
functionality.
