4.2 Button Locations and Descriptions
3P243520-7N
4 English
On/Off
Mode
Fan
Speed
Cancel
Button Locations and Descriptions
Functions other than basic operation items (i.e., On/Off, Operation
Mode, Fan Speed, and Setpoint) are set from the menu screen.
NOTE
Do not install the remote controller in places exposed to direct sunlight, the LCD Ɣ
will be damaged.
Do not pull or twist the remote controller cord, the remote controller may be Ɣ
damaged.
Do not use objects with sharp ends to press the buttons on the remote controller, Ɣ
damage may result.
2. Fan speed control
button
3. Menu/OK button
8. On/Off button
10. Cancel button
9. Operation lamp
11. LCD (with backlight)
4. Up button
5. Down button
6. Right button
7. Left button
1. Operation mode
selector button
