Names of Parts
Remote Controller
Signal transmitter
Receiver
• To use the remote controller, aim
the transmitter at the indoor unit. If
there is anything blocking the
signals between the unit and the
remote controller, such as a curtain,
the unit may not operate.
• The maximum transmission
distance is about 7m.
FAN setting button
• Selects the air ow rate setting.
Page 9
SUPER POWERFUL button
• SUPER POWERFUL operation.
Page 10
Explained by the HEAT PUMP model
HEAT PUMP model BRC086A11
COOLING ONLY model BRC086A12
Display (LCD)
• Displays the current settings.
(In this illustration, each section is
shown with all its displays on for the
purpose of explanation.)
TEMPERATURE
adjustment button
• Changes the temperature setting.
Page 8
ON/OFF button
• Press this button once to start
operation.
Press once again to stop it.
Page 7
Front cover
• Open the front cover.
Page 4
3
Read before Operation
01_EN_3P477582-2.indd 3 6/14/2017 14:12:41
To Next Page
