Names of Parts
Indoor Unit
Air inlet
Air outlet
Suction grille (sold separately)
• The suction grille is not included.
• The appearance of the suction grille may
differ between different models.
Air outlet grille (eld supply)
• This lamp is not used.
Indoor temperature sensor
• Detects the air temperature around
the unit.
TIMER lamp (orange)
OPERATION lamp (green)
Indoor unit ON/OFF switch
• Press this switch once to start operation. Press once again to stop it.
• For the operation mode setting, refer to the following table.
Model Mode Temperature setting Airow rate
HEATPUMP AUTO 25°C AUTO
COOLINGONLY COOL 22°C AUTO
• This switch can be used when the remote controller is missing.
Receiver
