Remote controller
• For details on remote controller operation, refer to the operation manual included with the remote controller.
Wired remote controller Wireless remote controller
Outdoor Unit
•The appearance of the outdoor unit may differ between different models.
Earth terminal (inside)
Refrigerant pipes and
inter-unit wire
Air outlet
Air inlet (back and side)
Model name
Drain hose
