ESIE09-08 PCB Layout for EKHBRD 011/014/016 AAV1
Refrigerant Circuit 33
Legend
*1: Only for EKHTS
*2: Only for benefit kWh rate power supply installation
Connector Color Connected to
X1A Blue -
X3A Orange X2M [12 - 13]
X4A Yellow -
X5A Black X2M [3 - 4]
X7A Pink 2-way valve (R-410A)
X8A Green Bridge with filter capacitors
X9A White -
X10A White X35A of PCB A1P -> 16V power supply
X11A Yellow R2T
*1
X12A Blue -
X13A White -
X14A White X3M [7 - 8]
*2
X15A Black X15A of PCB A1P
X16A Yellow Bridge
X21A White -
X23A White X2M [14 - 15 -16]
X25A White -
