15 | About the units and options
Installer and user reference guide
48
FAA71+100BUV1B
Split system air conditioner
4P654517-1 – 2021.03
(a)
To avoid condensation and water dripping out of the unit. If the temperature or the
humidity is beyond these conditions, safety devices may be put in action and the air
conditioner may not operate.
For combination with R32 outdoor unit, refer to the following table:
Outdoor units Cooling Heating
RZAG71~140 Outdoor
temperature
–20~52°C DB –20~24°C DB
–20~18°C WB
Indoor
temperature
17~38°C DB
12~28°C WB
10~27°C DB
RZASG71~140 Outdoor
temperature
–15~46°C DB –15~21°C DB
–15~15.5°C WB
Indoor
temperature
20~38°C DB
14~28°C WB
10~27°C DB
AZAS71+100 Outdoor
temperature
–5~46°C DB –15~21°C DB
–15~15.5°C WB
Indoor
temperature
20~38°C DB
14~28°C WB
10~27°C DB
RZA200+250 Outdoor
temperature
-20~46°C DB -20~15°C WB
Indoor
temperature
14~28°C WB 10~27°C DB
ARXM71 Outdoor
temperature
-10~46°C DB -15~18°C WB
Indoor
temperature
14~28°C WB 10~30°C DB
Indoor humidity ≤80%
(a)
—
(a)
To avoid condensation and water dripping out of the unit. If the temperature or the
humidity is beyond these conditions, safety devices may be put in action and the air
conditioner may not operate.
DB: Dry bulb
WB: Wet bulb
15.3 System layout
INFORMATION
The following illustration is an example and might NOT match your system layout.
