Daikin FAA100BUV1B - To Remove the Accessories from the Indoor Unit

14 | About the box
Installer and user reference guide
46
FAA71+100BUV1B
Split system air conditioner
4P654517-1 – 2021.03
FAA71 FAA100
14.2.2 To remove the accessories from the indoor unit
1 Remove:
▪ the accessory bag located at the bottom of the package,
▪ the mounting plate attached to the back of the indoor unit.
1×1× 1× 4× 1× 3× 1×
cba d e f g
a Installation and operation manual
b General safety precautions
c Fixing screws M4×25L for the mounting plate (9×), securing screws M4×12L (2× for
71 class, 3× for 100 class)
d Tie wraps (1 large, 3 small)
e Insulation tape
f Screws cover (for 100 class only)
g Mounting plate
