Daikin FTK(X)M-P Series User Manual

SiMT041509E Specifications
Specifications 4
1. Specifications
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTKM18PVMK FTKM24PVMK
Outdoor Unit RKM18PVMK RKM24PVMK
Capacity
Rated (Min. ~ Max.)
kW 5.28 (1.7 ~ 6.0) 7.03 (1.9 ~ 8.6)
Btu/h 18,000 (5,700 ~ 20,500) 24,000 (6,500 ~ 29,500)
kcal/h 4,540 (1,440 ~ 5,170) 6,050 (1,640 ~ 7,430)
Moisture Removal L/h 2.9 4.5
Running Current (Rated) A 6.4 - 6.1 - 5.8 / 6.4 - 6.1 8.8 - 8.4 - 8.1 / 8.8 - 8.4
Power Consumption
Rated (Min. ~ Max.)
W 1,350 (300 ~ 1,700) 1,890 (350 ~ 2,600)
Power Factor (Rated) % 95.9 - 96.2 - 97.0 / 95.9 - 96.2 97.6 - 97.8 - 97.2 / 97.6 - 97.8
COP
Rated (Min. ~ Max.)
W/W 3.91 (5.57 ~ 3.54) 3.72 (5.46 ~ 3.32)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 12.7 φ 12.7
Drain mm — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTKM18PVMK FTKM24PVMK
Front Panel Color (Mancel No.) White (N95) White (N95)
Airflow Rate
H
m³/min
(cfm)
20.5 (724) 22.0 (777)
M 16.5 (583) 17.7 (625)
L 12.6 (445) 13.7 (484)
SL 10.9 (385) 12.2 (431)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.45 - 0.43 - 0.41 / 0.45 - 0.43 0.70- 0.67 - 0.64 / 0.70 - 0.67
Power Consumption (Rated) W 59 85
Power Factor (Rated) % 59.6 - 59.7 - 60.0 / 59.6 - 59.7 55.2 - 55.2 - 55.3 / 55.2 - 55.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 259 340 × 1,050 × 259
Packaged Dimensions (H × W × D) mm 342 × 1,160 × 429 342 × 1,160 × 429
Weight (Mass) kg 15 15
Gross Weight (Gross Mass) kg 21 21
Sound
Pressure
Level
H / M / L / SL dB(A) 48 / 42 / 35 / 32 51 / 45 / 37 / 34
Outdoor Unit RKM18PVMK RKM24PVMK
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC40BXD 2YC40BXD
Motor Output W 1,300 1,300
Refrigerant
Oil
Type FW68DA FW68DA
Charge L 0.650 0.650
Refrigerant
Type R-32 R-32
Charge kg 1.12 1.40
Airflow Rate
H
m³/min
(cfm)
76.9 (2,715) 74.2 (2,620)
SL 62.0 (2,189) 61.4 (2,168)
Fan
Type Propeller Propeller
Motor Output W 128 128
Running Current (Rated) A 6.1 - 5.8 - 5.5 / 6.1 - 5.8 8.4 - 8.0 - 7.7 / 8.4 - 8.0
Power Consumption (Rated) W 1,291 1,805
Power Factor (Rated) % 96.2 - 96.8 - 97.8 / 96.2 - 96.8 97.7 - 98.1 - 97.7 / 97.7 - 98.1
Starting Current A 6.4 8.8
Dimensions (H × W × D) mm 695 × 930 × 350 695 × 930 × 350
Packaged Dimensions (H × W × D) mm 762 × 1,004 × 475 762 × 1,004 × 475
Weight (Mass) kg 46 49
Gross Weight (Gross Mass) kg 52 56
Sound
Pressure
Level
HdB(A) 51 56
Drawing No. 3D093404 3D093405
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
7.5 m
