Front Grille Si041352ED
4 Removal Procedure
2. Front Grille
Warning

Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Step Procedure Points
1. Remove the service
cover.

You can remove the front
grille without removing the
service cover.
1 Remove the screw, and
then the service cover.
2. Remove the front grille.
1 Remove the 3 screws
of the front grille.
2 Remove the 3 screw
covers with a flat
screwdriver.
3 Remove the lower 3
screws.
(R18714)
Service cover
(R9485)
Front grille
(R24476)
Screw cover
(R9488)
