Daikin FTXS35DAVMW(L) User Manual

Specifications SiENBE04-507A
14 Specifications
50Hz 230V
Note:  MAX. interunit piping length: 20m
 MAX. interunit height difference: 15m
 Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
 The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS35DVMW(9) FTKS35DVMW(9) FTKS35D2VMW
Outdoor Units RKS35DVMB RKS35D2VMB RKS35DVMB
Capacity
Rated (Min.~Max.)
kW 3.4 (1.4~3.8) 3.4 (1.4~3.8) 3.4 (1.4~3.8)
Btu/h 11,600 (4,750~12,950) 11,600 (4,750~12,950) 11,600 (4,750~12,950)
kcal/h 2,920 (1,200~3,270) 2,920 (1,200~3,270) 2,920 (1,200~3,270)
Moisture Removal L/h 1.9 1.9 1.9
Running Current (Rated) A 4.8 4.8 4.8
Power Consumption
Rated (Min.~Max.)
W 1,045 (300~1,270) 1,045 (300~1,270) 1,045 (300~1,270)
Power Factor % 94.7 94.7 94.7
COP
Rated (Min.~Max.)
W/W 3.25 (4.67~2.99) 3.25 (4.67~2.99) 3.25 (4.67~2.99)
Piping
Connections
Liquid mm φ 6.4 φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTKS35DVMW(9) FTKS35DVMW(9) FTKS35D2VMW
Front Panel Color White White White
Air Flow Rate
mł/min
(cfm)
H 8.9 (314) 8.9 (314) 8.9 (314)
M 6.9 (244) 6.9 (244) 6.9 (244)
L 4.8 (169) 4.8 (169) 4.8 (169)
SL 4.0 (141) 4.0 (141) 4.0 (141)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 40 40 40
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40
Power Factor % 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340 265×855×340
Weight kg 9 9 9
Gross Weight kg 12 12 12
Operation
Sound
H/L/SL dBA 39 / 26 / 23 39 / 26 / 23 39 / 26 / 23
Sound Power H dBA 57 57 57
Outdoor Units RKS35DVMB RKS35D2VMB RKS35DVMB
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600 600
Refrigerant
Oil
Type FVC50K FVC50K FVC50K
Charge L 0.375 0.375 0.375
Refrigerant
Type R-410A R-410A R-410A
Charge kg 1.0 1.0 1.0
Air Flow Rate
mł/min
cfm
H 33.5 (1,183) 33.5 (1,183) 33.5 (1,183)
L 23.4 (826) 23.4 (826) 23.4 (826)
Fan
Type Propeller Propeller Propeller
Motor Output W 50 50 50
Running Current (Rated) A 4.62 4.62 4.62
Power Consumption (Rated) W 1,005 1,005 1,005
Power Factor % 94.6 94.6 94.6
Starting Current A 4.8 4.8 4.8
Dimensions (H×W×D) mm 550×765×285 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 589×882×363 589×882×363 589×882×363
Weight kg 32 32 32
Gross Weight kg 38 38 38
Operation
Sound
H/L dBA 47 / 44 47 / 44 47 / 44
Sound Power H dBA 62 62 62
Drawing No. 3D049122A 3D050834 3D051047
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=mł/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
