1.2 Heat Pump
50Hz 230V
Note:  MAX. interunit piping length: 20m
 MAX. interunit height difference: 15m
 Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
 The data are based on the conditions shown in the table below.
Models
Indoor Units FTXS20DVMW(9) FTXS20DVMW(9)
Outdoor Units
RXS20DVMB RXS20D2VMB
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.0 (1.3~2.6) 2.7 (1.3~4.1) 2.0 (1.3~2.6) 2.7 (1.3~4.1)
Btu/h 6,820 (4,430~8,900) 9,210 (4,430~14,000) 6,820 (4,430~8,900) 9,210 (4,430~14,000)
kcal/h 1,720 (1,120~2,240) 2,320 (1,120~3,530) 1,720 (1,120~2,240) 2,320 (1,120~3,530)
Moisture Removal L/h 0.9 — 0.9 —
Running Current (Rated) A 2.7 3.6 2.7 3.6
Power Consumption
Rated (Min.~Max.)
W 490 (300~830) 660 (290~1,300) 490 (300~830) 660 (290~1,300)
Power Factor % 78.9 79.7 78.9 79.7
COP
Rated (Min.~Max.)
W/W 4.08 (4.33~3.13) 4.09 (4.48~3.15) 4.08 (4.33~3.13) 4.09 (4.48~3.15)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTXS20DVMW(9) FTXS20DVMW(9)
Front Panel Color White White
Air Flow Rate
mł/min
(cfm)
H 8.7 (307) 9.4 (332) 8.7 (307) 9.4 (332)
M 6.7 (237) 7.6 (268) 6.7 (237) 7.6 (268)
L 4.7 (166) 5.8 (205) 4.7 (166) 5.8 (205)
SL 3.9 (138) 5.0 (177) 3.9 (138) 5.0 (177)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16 0.16 0.16 0.16
Power Consumption (Rated) W 35 35 35 35
Power Factor % 95.1 95.1 95.1 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 38 / 25 / 22 38 / 28 / 25 38 / 25 / 22 38 / 28 / 25
Sound Power H dBA 56 56 56 56
Outdoor Units RXS20DVMB RXS20D2VMB
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 0.8 0.8
Air Flow Rate
mł/min
(cfm)
H 36.2 (1,278) 32.6 (1,151) 36.2 (1,278) 32.6 (1,151)
L 25.7 (907) 30.6 (1,080) 25.7 (907) 30.6 (1,080)
Fan
Type Propeller Propeller
Motor Output W 50 50
Running Current (Rated) A 2.54 3.44 2.54 3.44
Power Consumption (Rated) W 455 625 455 625
Power Factor % 77.9 79.0 77.9 79.0
Starting Current A 3.6 3.6
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 589×882×363 589×882×363
Weight kg 30 30
Gross Weight kg 35 35
Operation
Sound
H/L dBA 46 / 43 47 / 44 46 / 43 47 / 44
Sound Power H dBA 61 62 61 62
Drawing No. 3D049110A 3D050843
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=mł/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
