Daikin FTXTA30AW - Page 93

ESIE17-19C | Part 3. Repair 3.3. Unit specific repair procedures
19/08/19 | Version 1.1 Page 93
Optimized Heating 4
Figure 3-23: Locking the expansion valve motor
1. Expansion valve motor 4. Notch
2. Metal bracket 5. Expansion valve body
3. Nipples
1
23 3
4 5
