6
English
Outdoor Unit
Appearance of the outdoor unit may differ from some models.•
CAUTION
The surface of the radiant panel becomes very •
hot during RADIANT operation. Do not touch
the panel of the main unit directly.
After the operation is complete, do not remove
or care and clean the panel until the surface
temperature of the panel decreases.
Open the front panel
Strings
Air fi lter (upper)
Front panel stopper
Air fi lter (lower)
Outdoor temperature
sensor (back)
Drain hose
Model name plate
Refrigerant piping and
inter-unit wiring
Earth terminal
It is inside of this cover.•
Titanium apatite
photocatalytic
air-purifying fi lter
It is inside of air fi lter (lower).•
Air inlet
(back and side)
Air outlet
01_EN_3P276869-1A.indb 601_EN_3P276869-1A.indb 6 8/8/2012 4:18:10 PM8/8/2012 4:18:10 PM
