7
Name of Parts
Remote Controller
Signal transmitter
Receiver
To use the remote controller, aim the •
transmitter at the indoor unit. If there
is anything to block signals between
the unit and the remote controller,
such as a curtain, the unit will not
operate.
Do not drop the remote controller. Do •
not get it wet.
The maximum distance for communi-•
cation is approximately 7m.
FAN setting button
It selects the airfl ow rate setting.•
Page 15
►
TEMPERATURE
adjustment buttons
It changes the temperature setting.•
Page 13
►
ON/OFF button
Press this button once to start •
operation.
Press once again to stop it.
Page 11
►
Front cover
Open the front cover. •
Page 8
►
Display (LCD)
It displays the current settings.•
(In this illustration, each section is
shown with its displays on for the
purpose of explanation.)
RADIANT switching button
RADIANT operation. •
Page 12
►
Model ARC466A2
01_EN_3P276869-1A.indb 701_EN_3P276869-1A.indb 7 8/8/2012 4:18:10 PM8/8/2012 4:18:10 PM
