ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER 38 www.DaikinApplied.com
ComprehensIve daTa Tables
Table 19: Network Variable Outputs (NVOs) - SmartSource Single and Two Stage Compressor and Ennity Large Two
Compressor, Continued
Point Name
lonWorks Variable
(NV Index
2
)
SNVT Type
(SNVT Index)
Range/
Default
(in Units)
Heart-
beat
Description
Network Variable Outputs (NVOs)
Compressor #1
Suction Temperature
nvoSuctionTemp1
(41)
SNVT_temp_p
(105)
0 to 158ºF
17.77 to 70ºC
Default
1
:
621.806ºF
327.67ºC
No
Indicates the compressor #1 suction line temperature sensor
value.
1
Compressor #2
Suction Temperature
nvoSuctionTemp2
(SS2C: 42)
SNVT_temp_p
(105)
0 to 158ºF
17.77 to 70ºC
Default
1
:
621.806ºF
327.67ºC
No
Indicates the compressor #2 suction line temperature sensor
value.
1
Applies only to Ennity Large Two Compressor (SS2C) units.
Condensate Overow
Status
nvoCondOverow
(30)
SNVT_switch
(95)
Default: Null No
Monitors the Condensate Overow sensor input.
Selection State Value
Dry 0 0%
Wet 1 100%
Null -1 0 to 100%
Current Alarm
nvoCurrentAlarm
(31)
SNVT_str_asc
(36)
Init: No Alarms No
Displays the current highest active alarm.
SmartSource (Series2) Alarm Strings
• No Alarms
• IO Exp Communication Fail
• Invalid Conguration
• Low Voltage Brownout
• Comp High Pressure
• Comp Low Pressure
• Comp Suctn Temp Snsr Fail
• Comp Low Suction Temp
• Freeze Fault Detect
• Room Temp Sensor Fail
• Entering Water Temp Snsr Fail
• Leaving Water Temp Snsr Fail
• Condensate Overow
• Low Entering Water Temp
• Serial EEPROM Corrupted
• Wtrside Econ Low Temp Cutout
Ennity Large Two Comp (SS2C) Alarm Strings
• No Alarms
• IO Exp Communication Fail
• Invalid Conguration
• Low Voltage Brownout
• Comp #1 High Pressure
• Comp #2 High Pressure
• Comp #1 Low Pressure
• Comp #2 Low Pressure
• Comp #1 Suctn Temp Snsr Fail
• Comp #2 Suctn Temp Snsr Fail
• Comp #1 Low Suction Temp
• Comp #2 Low Suction Temp
• Freeze Fault Detect
• Room Temp Sensor Fail
• Entering Water Temp Snsr Fail
• Leaving Water Temp Snsr Fail
• Condensate Overow
• Low Entering Water Temp
• Serial EEPROM Corrupted
• Wtrside Econ Low Temp Cutout
Discharge Air
Temperature
nvoDischAirTemp
(32)
SNVT_temp_p
(105)
0 to 158ºF
17.77 to 70ºC
Default
1
:
621.806ºF
327.67ºC
Send Indicates the Discharge Air Temperature sensor value.
1
1. Analog Null (0x7FFF) is a discrete temperature value of 621.806ºF/327.67ºC. Its purpose is to indicate a sensor failure condition or when the unit controller is not
using that temperature value.
2. The Network Variable index number is a unique identier for certain LonWorks variables. Some BAS companies use this numeric value instead of text to
reference these variables. The NV index number can also be found in the XIF le.
3. After Receive Heartbeat is enabled, this variable reverts to the default (non-override) value if it is not refreshed often enough through a network command or if
communication is disabled (i.e. the device is disabled or is ofine).
4. The totalizer continues to increment until the maximum count is reached, at which point the BAS must reset the value by issuing a write command. The variable is
saved in nonvolatile memory every 24 hours. If power is lost, that day’s totalizer information is not stored.
