ComprehensIve daTa Tables
www.DaikinApplied.com 39 ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER
Table 19: Network Variable Outputs (NVOs) - SmartSource Single and Two Stage Compressor and Ennity Large Two
Compressor, Continued
Point Name
lonWorks Variable
(NV Index
2
)
SNVT Type
(SNVT Index)
Range/
Default
(in Units)
Heart-
beat
Description
Network Variable Outputs (NVOs)
Effective Occupancy
Output
nvoEffectOccup
(33)
SNVT_occupancy
(109)
Init: OC_NUL Send
Indicates the unit’s current occupancy mode. The mode in
which the unit operates depends on Occupancy Schedule,
Occupancy Schedule Override or an occupancy sensor.
nvoEffectOccup uses the local sensor unless nviOccManCmd,
nviOccSchedule or nviOccSensor network overrides are not
in a “OC_NUL” state. See Effective Occupancy Modes.
Supported Values
0 = OC_OCCUPIED
1 = OC_UNOCCUPIED
2 = OC_BYPASS
3 = OC_STANDBY
-1 (0xFF) = OC_NUL
Effective Setpoint
Output
nvoEffectSetpt
(SmartSource: 47)
(SS2C: 48)
SNVT_temp_p
(105)
50 to 95ºF
10 to 35ºC
Default
1
:
621.806ºF
327.67ºC
Send
Effective Heating or Cooling setpoint the unit is attempting
to maintain, which depends on Effective Occupancy
(nvoEffectOccup).
1
See Effective Occupancy Modes.
Effective Space
Temperature Output
nvoSpaceTemp
(26)
SNVT_temp_p
(105)
0 to 158°F
-17.77 to 70°C
Default
1
:
621.806ºF
327.67ºC
Send
Monitors the space temperature used by the unit.
nvoSpaceTemp uses the nvoLocalSpaceTmp local sensor
unless the nviSpaceTemp network override is a valid value.
1
Entering Water
Temperature
nvoEWT
(34)
SNVT_temp_p
(105)
0 to 158ºF
17.77 to 70ºC
Default
1
:
621.806ºF
327.67ºC
No Indicates the Entering Water Temperature sensor value.
1
Fan ON/Auto
Switch Status
(Room Sensor)
nvoFanOnAuto
(35)
SNVT_switch
(95)
Init: Null No
Displays the room sensor fan ON/Auto switch position.
Selection State Value
Fan On 0 0%
Fan Auto 1 100%
Null -1 0 to 100%
Fan Speed Output
nvoFanSpeed
SmartSource (46)
Ennity SS2C (47)
SNVT_switch
(95)
Init: OFF Send
Displays the commanded fan speed.
SmartSource (Series2)
Fan Speed State Value
OFF 0 0%
Running 1 0 to 100%
Ennity Large Two Compressor (SS2C)
Fan Speed State Value
OFF 0 0%
ON 1 100%
System Mode Switch
(Heat/Cool/Auto)
Status
nvoHeatCoolAuto
SmartSource (43)
Ennity SS2C (44)
UNVTheatCoolAuto Init: HCA_NUL No
Displays the room sensor System Mode switch
(Heat/Cool/Auto) position.
Supported Values
0 = HCA_OFF
1 = HCA_HEAT
2 = HCA_COOL
3 = HCA_AUTO
-1 (0xFF) = HCA_NUL (no switch present)
Humidistat Sensor
Status
nvoHumidistat
SmartSource (48)
Ennity SS2C (49)
SNVT_switch
(95)
Default: Null No
Status of the Humidistat/Cooling Stage #1 sensor input.
Signal input represents Humidistat for units with the HGR
option. For all other units, it is the thermostat Cooling Stage
#1 request. Input is active (Is Humid) when 24VAC is applied.
Selection State Value
Not Humid 0 0%
Is Humid 1 100%
Null -1 0 to 100%
Leaving Water
Temperature Output
nvoLWT
(36)
SNVT_temp_p
(105)
0 to 158°F
-17.77 to 70°C
Default
1
:
621.806ºF
327.67ºC
No Indicates the Leaving Water Temperature sensor value.
1
1. Analog Null (0x7FFF) is a discrete temperature value of 621.806ºF/327.67ºC. Its purpose is to indicate a sensor failure condition or when the unit controller is not
using that temperature value.
2. The Network Variable index number is a unique identier for certain LonWorks variables. Some BAS companies use this numeric value instead of text to
reference these variables. The NV index number can also be found in the XIF le.
3. After Receive Heartbeat is enabled, this variable reverts to the default (non-override) value if it is not refreshed often enough through a network command or if
communication is disabled (i.e. the device is disabled or is ofine).
4. The totalizer continues to increment until the maximum count is reached, at which point the BAS must reset the value by issuing a write command. The variable is
saved in nonvolatile memory every 24 hours. If power is lost, that day’s totalizer information is not stored.
