ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER 40 www.DaikinApplied.com
ComprehensIve daTa Tables
Table 19: Network Variable Outputs (NVOs) - SmartSource Single and Two Stage Compressor and Ennity Large Two
Compressor, Continued
Point Name
lonWorks Variable
(NV Index
2
)
SNVT Type
(SNVT Index)
Range/
Default
(in Units)
Heart-
beat
Description
Network Variable Outputs (NVOs)
Local Setpoint Adjust
Output
nvoSetpoint
SmartSource (44)
Ennity SS2C (45)
SNVT_temp_p
(105)
55 to 95ºF
12.78 to 35ºC
Default
1
:
621.806ºF
327.67ºC
Send
The reference setpoint used to determine the Effective
Heating/Cooling setpoints. It is the value of the local,
hardwired space temperature setpoint. It is only valid if the
unit controller JP5 conguration jumper is congured for Long
Range Setpoint Adjust and is enabled by nciLocSptEnable.
1
See Effective Occupancy Modes.
Local Space
Temperature Output
nvoLocalSpaceTmp
(38)
SNVT_temp_p
(105)
0 to 158°F
-17.77 to 70°C
Default
1
:
621.806ºF
327.67ºC
Send
The value of the hardwired space temperature sensor
installed either in the return air or in the space. Writing to
Space Temp Input (nviSpaceTemp) does not affect Local
Space Temp (nvoLocalSpaceTmp) but does affect Effective
Space Temp (nvoSpaceTemp).
1
McQuay WSHP
Status
nvoMcQHPUnitStat
(SmartSource: 42)
(SS2C: 43)
UNVTmcqHPUnitStat Init: UNIT_NULL No
Indicates the unit’s operating state.
Supported Values
0 = MUS_OFF_ALARM
1 = MUS_OFF
2 = MUS_START
3 = MUS_FAN ONLY (fan is allowed to operate)
4 = MUS_PREPARE_TO_HEAT
5 = MUS_HEATING
6 = MUS_PREPATE_TO_COOL
7 = MUS_COOLING
8 = MUS_PREPATE_TO_DEHUMIDIFY
9 = MUS_DEHUMIDIFICATION
-1 (0xFF) = UNIT_NULL
Previous Alarm
nvoPreviousAlarm
(39)
SNVT_str_asc
(36)
Init: No Alarms No
Indicates the previous unit fault.
SmartSource (Series2) Alarm Strings
• No Alarms
• IO Exp Communication Fail
• Invalid Conguration
• Low Voltage Brownout
• Comp High Pressure
• Comp Low Pressure
• Comp Suctn Temp Snsr Fail
• Comp Low Suction Temp
• Freeze Fault Detect
• Room Temp Sensor Fail
• Entering Water Temp Snsr Fail
• Leaving Water Temp Snsr Fail
• Condensate Overow
• Low Entering Water Temp
• Serial EEPROM Corrupted
• Wtrside Econ Low Temp Cutout
Ennity Large Two Compressor (SS2C) Alarm Strings
• No Alarms
• IO Exp Communication Fail
• Invalid Conguration
• Low Voltage Brownout
• Comp #1 High Pressure
• Comp #2 High Pressure
• Comp #1 Low Pressure
• Comp #2 Low Pressure
• Comp #1 Suctn Temp Snsr Fail
• Comp #2 Suctn Temp Snsr Fail
• Comp #1 Low Suction Temp
• Comp #2 Low Suction Temp
• Freeze Fault Detect
• Room Temp Sensor Fail
• Entering Water Temp Snsr Fail
• Leaving Water Temp Snsr Fail
• Condensate Overow
• Low Entering Water Temp
• Serial EEPROM Corrupted
• Wtrside Econ Low Temp Cutout
1. Analog Null (0x7FFF) is a discrete temperature value of 621.806ºF/327.67ºC. Its purpose is to indicate a sensor failure condition or when the unit controller is not
using that temperature value.
2. The Network Variable index number is a unique identier for certain LonWorks variables. Some BAS companies use this numeric value instead of text to
reference these variables. The NV index number can also be found in the XIF le.
3. After Receive Heartbeat is enabled, this variable reverts to the default (non-override) value if it is not refreshed often enough through a network command or if
communication is disabled (i.e. the device is disabled or is ofine).
4. The totalizer continues to increment until the maximum count is reached, at which point the BAS must reset the value by issuing a write command. The variable is
saved in nonvolatile memory every 24 hours. If power is lost, that day’s totalizer information is not stored.
