Table 36 continued: Manual Control Menu
Item Display Name Default Setting Range Password Level
GasHtg OnOff= OFF
OFF
4
ON
Htg Valve= 0% 0–100% 4
SCR Out= 0% 0–100% 4
F&BP Damper= 0% 0–100% 4
Htg Stg 1= OFF
OFF
4
ON
SCR Ena 1= OFF
OFF
4
ON
Htg Stg 2= OFF
OFF
4
ON
SCR Ena 2= OFF
OFF
4
ON
Htg Stg 3= OFF
OFF
4
ON
Htg Stg 4= OFF
OFF
4
ON
Htg Stg 5= OFF
OFF
4
ON
Htg Stg 6= OFF
OFF
4
ON
Reheat Valve= 0% 0–100% 4
RH Output= OFF
OFF
4
ON
LSCRH Valve= 0% 0–100% 4
HGBP Valve= OFF
OFF
4
ON
ERec Wheel= OFF
OFF
4
ON
ER Whl Cmd= 0% 0–100% 4
ERBP Dmpr Cl= OFF
OFF
4
ON
ERBP Dmpr Op= OFF
OFF
4
ON
Cond Wtr Pump= OFF
OFF
4
ON
Alm Output= OFF
OFF
4
ON
Fan Op Out= OFF
OFF
4
ON
Manual Ctrl is an adjustable item that puts the unit into manual
control. Major components of the unit are turned on and off by
this control. The units normal control sequences are overridden
in this state with the exception of all the “fault” alarms and the
cooling circuit high pressure and low pressure alarms.
Supply Fan is an adjustable item that turns on the supply fan.
RF/EF is an adjustable item that turns ON the return/exhaust fan.
SAF Spd Cmd is an adjustable item only on VAV units that
sets the speed of the supply air fan.
RF/EF Spd Cmd is an adjustable item for units with VFD
on the return/exhaust fans that sets the speed of the return/
exhaust fan.
OAD/Econo is an adjustable item which is used to set the
economizer damper position.
OAD OpCl is an adjustable item which is used to turn the
OA damper output ON. This output is available only on self
contained units.
Var Cmp is an adjustable item used in manual control to turn on
the variable speed compressor
Var Cmp Cmd is an adjustable item used in manual control to sets
the speed of the variable speed compressor
VCmp Emg Stop is an adjustable item used in manual control to
test the variable speed compressor Emergency Stop function
Comp 1 OnOff is an adjustable item that turns on compressor #1.
Comp 2 OnOff is an adjustable item that turns on compressor #2.
Comp 3 OnOff is an adjustable item that turns on compressor #3.
Comp 4 OnOff is an adjustable item that turns on compressor #4.
Comp 5 OnOff is an adjustable item that turns on compressor #5.
Comp 6 OnOff is an adjustable item that turns on compressor #6.
Comp 7 OnOff is an adjustable item that turns on compressor #7.
Comp 8 OnOff is an adjustable item that turns on compressor #8.
