Daikin ONE - Installation

2 www.daikincomfort.com IO-DPV
14⅞"
10⅛"
11½"
6"
6"
Installation
Only a heang/air condioning installer or qualied service
person should install your venlator, unless you
are completely familiar with the necessary tools,
equipment and potenal hazards involved. If you plan to
install this venlator yourself, please be aware that the
improper use of any tool can be dangerous. Daikin will
not assume any responsibility for failures due to incorrect
installaon procedures.
• Homeowners can perform the basic maintenance
funcon of replacing lters.
• When working on the venlator, observe precauons
in this manual, labels aached to the furnace or air
handler, and other safety precauons that may apply.
• Follow all safety codes. Wear safety glasses and
work gloves.
Descripon
The Daikin One Powered Venlator is a cost-eecve mechanical
venlaon soluon that helps manage the humidity and tempera-
ture in a home. Contractors and builders now have a praccal
oering for supplying constant outdoor air into the residence,
meeng the venlaon requirements per ASHRAE guidelines.
Proprietary Noce
This document and the informaon disclosed herein are proprietary
data of Daikin North America LLC. Neither this document nor
the informaon contained herein shall be reproduced, used, or
disclosed to others without the wrien authorizaon of Daikin
North America LLC, except to the extent required for installaon or
maintenance of recipient’s equipment.
Copyright Noce
Copyright 2020, Daikin North America LLC All rights reserved.
Liability Noce
Daikin North America LLC does not accept any liability for
installaons of venlaon equipment installed by unqualied
personnel or the use of parts/components/lters/equipment that
are not authorized or approved by Daikin.
Specicaons
WARNING!
This symbol indicates important instrucons. Failure to heed
them can result in serious injury or death.
i
WARNING!
Before beginning any installaon or modicaon, be certain
that the main line electrical disconnect switch is in the OFF
posion. Unexpected start-up of system blower may cause
serious injury. Tag disconnect switch with suitable
warning labels.
WARNING!
This product can expose you to a chemical (or chemicals)
known to the State of California to cause cancer.
WARNING!
This product can expose you to a chemical (or chemicals)
known to the State of California to cause reproducve toxicity.
i
i
i
CAUTION!
This symbol indicates important instrucons. Failure to heed
them can result in injury or material property damage.
CAUTION!
i
i
Read and save these instrucons
Important: Read and save these instrucons. This guide to be le with equipment owner.
i
Replacement Media Filters
Replacement Filter Part
MERV 16 DQ-P-F-16
MERV 13 DQ-P-F-13
Table 1 - Power consumpon of Venlator at various owrates
Flow Rate @ 0.2" w.c.
(CFM) Power (W)
100 26.3
90 21.8
80 19.5
70 17.1
60 15.1
50 13
40 11.3
12"
9½"
