Daikin RCS - RTU;SCU;MPS;DPS;DPH Expansion Module E I;O

Table 13: RTU/SCU/MPS/DPS/DPH Expansion Module E I/O
I/O Cong. Code Condition
Expansion Module E
Pos. 1 = 0, 1, 2, 3 or 4
Simultaneous OA Flow and CO
2
OA Reset
Universal Inputs/Outputs
# DI AI DO AO Point Comments Cong. Code Condition
X 1 X OA Flow 0–10 VDC or 4–20 mA 1 = 0 & 8 = 1, 2, 3, 5, 6 or 7 & 9 = 6
X 2
X 3
X 4
X 5
X 6
X 7
X 8
Digital Outputs — Relay (SPST, Normally Open, 230 VAC 3 Amp)
# Point Comments Cong. Code Condition
DO 1
DO 1
DO 2
DO 2
DO 3
DO 4
Digital Outputs — Triac (24 VAC, 0.5 Amp)
# Point Comments Cong. Code Condition
DO 5
DO 6
ConTroller InpuTs/ouTpuTs
