Daikin RXR28EV1B9 - Remove Humidifier Unit and Duct

Removal of Humidifier Unit Si00-777
4 Removal Procedure
4
Remove the 4 screws
of the humidifier unit
and lift it up to remove.
5
The figure shows the
positions of the
humidifying duct and
the relay connectors.

When installing the
humidifier unit, do not forget
to connect the relay
connectors.
Step Procedure Points
(R13984)
Humidifier unit
Relay
connector
Humidifying
duct
(R13985)
