3.4.3 Chargingrefrigerant:Setup
See"3.3.1Checkingrefrigerantpiping:Setup"onpage6.
3.4.4 Tochargerefrigerant
WARNING
▪ OnlyuseR410A asrefrigerant.Othersubstancesmay
causeexplosionsandaccidents.
▪ R410Acontainsfluorinatedgreenhousegasescovered
by the Kyoto Protocol. Its global warming potential
value is 1975. Do NOT vent these gases into the
atmosphere.
▪ When charging refrigerant, always use protective
glovesandsafetyglasses.
Prerequisite:Beforechargingrefrigerant,makesuretherefrigerant
pipingisconnectedandchecked(leaktestandvacuumdrying).
1 Connectthe refrigerant cylinder toboth the service portof the
gasstopvalveandtheserviceportoftheliquidstopvalve.
2 Chargetheadditionalrefrigerantamount.
3 Openthestopvalves.
3.4.5 Tofixthefluorinatedgreenhousegases
label
1 Fillinthelabelasfollows:
c
b
a
a Factoryrefrigerantcharge:seeunitnameplate
b Additionalrefrigerantamountcharged
c Totalrefrigerantcharge
2 Thefilledoutlabelmustbeadheredontheinsideoftheproduct
and in the proximity of the product charging port (e.g., on the
insideoftheservicecover).
3.5 Connectingtheelectricalwiring
DANGER:RISKOFELECTROCUTION
WARNING
ALWAYSusemulticorecableforpowersupplycables.
CAUTION
For use of units in applications with temperature alarm
settings it is recommended to foresee a delay of 10
minutes for signalling the alarm in case the alarm
temperature is exceeded. The unit may stop for several
minutesduringnormaloperationfor"defrostingtheunit",or
whenin"thermostatstop"operation.
3.5.1 Aboutelectricalcompliance
AZQS_V1+AZQS125_Y1
Equipment complying with EN/IEC 61000312 (European/
International Technical Standard setting the limits for harmonic
currents produced by equipment connected to public lowvoltage
systemswithinputcurrent>16Aand≤75Aperphase.).
AZQS140_Y1
Equipmentcomplyingwith:
▪ EN/IEC 61000312 provided that the shortcircuit power S
sc
 is
greater than or equal to the minimum S
sc
 value at the interface
pointbetweentheuser'ssupplyandthepublicsystem.
▪ EN/IEC 61000312 = European/International Technical
Standard setting the limits for harmonic currents produced by
equipment connected to public lowvoltage systems with input
current>16Aand≤75Aperphase.
▪ Itistheresponsibilityoftheinstalleroruseroftheequipmentto
ensure,byconsultationwiththedistributionnetworkoperatorif
necessary, that the equipment is connected only to a supply
with a shortcircuit power S
sc
 greater than or equal to the
minimumS
sc
value.
Model MinimumS
sc
value
AZQS140_Y1 1170kVA
(a)
(a) Thisisthemoststringentvalue.Forspecificproductdata,
seethedatabooks.
